CISA FAST PUSH 59016-10 Černý - 2 bodový mechanismus panikového kování povrchového

Popis

---

---

CISA FAST PUSH 059016-10 - Mechanismus panikového kování dvoubodového pro pevné křídlo dvoukřídlých dveří.

DODÁVÁNO BEZ VODOROVNÉ TRUBKY A BEZ SVISLÝCH TÁHEL A PROTIKUSŮ !!!

Technical features:
• Painted aluminum alloy/aluminum cover
• Chrome aluminum alloy self-locking latchbolt.

Supplied as standard:
• Special strikers
• Fixing screws
• ICIM and CE certificates of compliance
• Installation and maintenance Instructions

On request:
• External drives
• Extended bolts
• Version with microswitch (spec. LA)
• Version with hold open device (spec. FG)
• Fire door version with steel latchbolt (FR spec.).

Finishes:
• STANDARD:
• Painted black
• ON REQUEST (only item 1.59011.10.0):
Painted red (fin. 41)
Painted yellow (fin. 42)
Painted green (fin. 43)
Painted white (fin. 45)
Painted gray (fin. 97)
PVD treatment: satin-finished stainless steel (fin. C2)

Standards:
• CE mark according to the 89/106/EEC DIRECTIVE granted by ICIM
• Voluntary product certification granted by the independent certifying body ICIM according to the standard UNI EN 1125

Hand: 0 = Non-handed
Bar to be ordered separately series 07007

• MODULAR VERSION WITHOUT CENTRAL latch bolt
• Can be used with:
Pair of top/bottom latch bolts item 1.07063.61.0
Pair of lateral latch bolts item 1.07063.51.0
Pair of top/lateral latch bolts item 1.07063.66.1/2
Pair of top/bottom dead-bolts item 1.07063.71.0
• ON REQUEST:
Striker item 1.07072.21.0 Outside operation devices item 1.07078.28/29.0, 1.07077.46/47/48.0
